China Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming Machine

ZhongHeng Machine Manufacture Co.,Ltd
Contact Now

China Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming Machine

Brand Name : ZHONGHENG

Model Number : ZH 960

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : 22,000 USD

Payment Terms : L/C, T/T

Supply Ability : 50 sets /month

Delivery Time : 40 working days

Packaging Details : with plastic film cover

Material width : 1200mm

Material : PPGI ,Aluninum,Gi

Motor : 7.5kw

Pump motor : 5.5kw

Forming Stations : 15

Contact Now

                                                       China Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming Machine

China Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming Machine

Specifications





1



Power Requirement



Voltage 380v/3ph/50hz
Main Motor power 7.5kw hydraulic motor
2 Forming speed 8-15m/min
3 Forming stations 15
4 Thickness of structure 16mm
5 Forming shaft diameter 75mm
6 Chains 1 inch
7 H steel 350mm
8 Sleeve galvanized pipe with color coating
9 Screen Text screen /touch screen
10 Type of cutting Roll formed and length-set cutting
9. Control system PLC Delta and Inveter Delta
10. Install dimension(depend on the final design) 8.2m×1.5m×1.2m
11. Total weight (Approx) 6.5T



Machine pictures



China Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming MachineChina Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming MachineChina Low Price Steel Glazed Tile Trapezoidal Tile Roofing Sheet Roll Forming Machine



Components of line





1) Manual De-coiler ------------------------------------------------------ 1 set

2) Guiding Device--------------------------------------------------------- 1 set

3) Roll Forming System--------------------------------------------------- 1set

4) Cutting Device---------------------------------------------------------- 1set

5) Hydraulic System------------------------------------------------------- 1 set

6) PLC Control System-----------------------------------------------------1 set

7) Run out table ----------------------------------------------------------- 1 set





Spare parts list



No. Item Qty
1 Limited switch 2
2 Chains 1
3 Value 1
4 Relay 1
5 Chains Joint 2
6 Encoder wheels 2
